The Wirecast Gear 3 4K 12G-SDI Streaming System from Telestream is a live streaming video switcher encased in a compact, rack-mountable chassis that is ideal for creating news programming, worship services, sports, and other live events. Equipped with four 12G-SDI inputs and four Mini DisplayPort outputs, with support for resolutions up to DCI 4K60, the switcher takes full advantage of the power of its six-core/12-Thread AMD Ryzen Processor and NVIDIA Quadro Graphics Card.
The Wirecast Gear 3 has 16 GB of DDR4-3200 system memory, two Gigabit Ethernet ports, a 1 TB SSD for internal storage, and it comes with Wirecast Pro software and a stock media library. The system operates on Windows 10 loT Enterprise LTSC 2021, which ensures native support for widely used conferencing applications like Microsoft Teams and Zoom.
|
Telestream WCG3-4K-SDI-620 Specification Processing |
|
| Switching Type | Software |
| Processing Resolution | DCI 4K at 60 |
| Color Processing | 4:2:2YUV |
|
Input |
|
| Video Inputs | 4 x BNC (12G-SDI) Female 1 x BNC (3G-SDI) Female |
| Input Video Format | SDI (4:2:2 YUV) DCI 4K up to 60 fps 1080p up to 60 fps |
| Audio Inputs | 2 x 1/8" / 3.5 mm TRS Stereo Analog Female 1 x 1/8" / 3.5 mm TS Mono Analog Female |
| Input Audio Format | Analog |
| Embedded Audio Input | HDMI SDI |
|
Output |
|
| Video Outputs | 4 x Mini DisplayPort (DisplayPort 1.4) 1 x BNC (3G-SDI) Female (Preview) |
| Output Video Format | Mini DisplayPort DCI 4K up to 60 fps |
| Audio Outputs | 2 x 1/8" / 3.5 mm TRS Stereo Analog Female 1 x TOSLINK S/PDIF Female |
| Output Audio Format | Analog S/PDIF |
|
Connectivity |
|
| Other I/O | 2 x RJ45 LAN, NDI Input/Output 1 x USB-C 3.1/3.2 Gen 2 5 x USB-A 3.1/3.2 Gen 2 4 x USB-A 3.0 / 3.1/3.2 Gen 1 |
| Video Standard Compliance | SMPTE 424M/ST-2082 |
|
Hardware |
|
| OS Compatibility | Windows 10 or Later *As of December, 2022: Check with manufacturer for the most up-to-date compatibility |
| Processor | AMD Ryzen 5 5600 X |
| CPU | Up to 4.6 GHz 6-Core |
| GPU | NVIDIA Quadro |
| Wi-Fi | None |
| Bluetooth | None |
|
Power |
|
| Power I/O | 1 x IEC C14 Input |
|
Environmental |
|
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 185°F / -20 to 85°C |
| Operating Humidity | 20 to 80% |
| Storage Humidity | 10 to 90% |
|
General |
|
| Rack Form Factor | 2 RU |
| Dimensions (W x H x D) | 16.7 x 12 x 3.5" / 42.4 x 30.5 x 8.9 cm |
| Weight | 15.5 lb / 7 kg |
- Telestream Wirecast Gear 3 4K 12G-SDI Streaming System
- Wireless Keyboard
- Wireless Mouse
- 2 x Battery for Keyboard & Mouse
- USB Wireless Dongle
- 4 x Mini DisplayPort to DisplayPort Adapter
- IEC Power Cord (6')
- Limited 1-Year Manufacturer Warranty
