Compatibility
The RM-IP10 is compatible with Sony BRC camera models:
BRC-H900
BRC-Z330
BRC-Z700
It is also compatible with the following cameras when they are fitted with the BRBK-IP10 option board:
BRC-X400
SRG-X400
SRG-X120
BRC-H900
BRC-H900
BRC-H800
BRC-X1000
SRG-300SE
SRG-300H
SRG-120DU
SRG-120DH
SRG-120DS
It is also compatible with the following camera when it is fitted with the BRBK-IP7Z option board:
BRC-Z700
OS Requirements
Microsoft Windows 7, 32-/64-bit
Windows 8.1 Pro, 32-/64-bit
Windows 10 Pro, 32-/64-bit
Computer Requirements
Intel Core 2 Duo 2.4 GHz or Higher
1 GB or more RAM
50MB or more hard drive space
10/100 RJ45 Ethernet port
Key Features
- Comfortable PTZ operation with the optical 3-axis joystick
- Versatile camera adjustment by simple panel operation
- Use of IP technology allows for flexible installation and easy operation
- Preset feature saves camera settings (up to 16 positions)
Sony RM-IP10 Specification General |
|
Number of Supported Cameras | 112 Channels via IP 7 Channels via Serial |
Supported Control Protocols | IP RS-232 RS-422 VISCA |
Control I/O | 1 x Mini-DIN 8-Pin (RS-232) Output |
Other I/O | 1 x DIN 9-Pin (RS-422) Output 1 x RJ45 (LAN) Output |
Controls | 1 x Joystick 3 x Knobs 14 x Buttons |
Power |
|
PoE Support | None |
Power Connectors | 1 x JEITA |
Power Consumption | 3.6 W |
DC Input Power | 10 to 13.2 VDC at 0.3 A |
Environmental |
|
Operating Temperature | 32 to 104°F / 0 to 40°C |
Storage Temperature | -4 to 140°F / -20 to 60°C |
Physical |
|
Security Lock Support | None |
Dimensions | 15.5 x 6.5 x 5.75" / 391.3 x 165 x 145.9 mm |
Weight | 2.1 lb / 950 g |
- Sony RM-IP10 IP Remote Controller for BRC Cameras
- AC Adapter
- AC Power Cord
- 2 x RS-422 Terminal Connector
- Limited 1-Year Manufacturer Warranty
