- Enhanced Pan/Tilt/Zoom (PTZ) operation
Accurately re-frame shots or track moving subjects with smooth, speedy, near-silent remote control of pan, tilt and zoom functions. There's also low-speed zoom and a slow pan/tilt mode for precise, judder-free camera movements. PTZ Trace Memory allows a sequence of camera movements to be memorised and followed whenever required. PTZ Motion Sync smoothly blends separate pan, tilt and zoom movements for seamless, professional-looking transitions. Up to 100 pre set positions for pan/tilt/zoom operations -
High quality 12x optical zoom and 18x(4K) or 24x(HD) with Clear Image Zoom
The high quality Zeiss Vario-Sonnar T* lens with 12x optical zoom range covers wide angle shots as well as tight close-ups. Clear Image Zoom* expands this range to 18x (4K) or 24x (HD) without sacrificing detail. In addition, the Tele Convert Mode can double this range again, up to 48x zoom while maintaining a 1920x1080 resolution.*Clear Image Zoom is a Sony original intelligent interpolation, which analyzes the input image and increases the resolution of the image.
-
RCP/MSU Connectivity
In an studio environment, BRC-X1000 can be controlled via Sony’s Remote Control Panel RCP-1500/1501/1530 and MSU-1000/1500. Connection can be made over IP networks.*The compatibility is described in Remote Camera System Guide.
- Versatile video outputs
Enjoy greater installation flexibility in professional broadcast and AV environments with dual link 3G-SDI (x4) and HDMI video outputs. - Always up to date
New camera functionality and performance improvements can be added via firmware updates over IP. - Uncompromising 4K images
The camera's large, back-illuminated 1.0-type Exmor R CMOS sensor delivers uncompromised broadcast quality colour pictures in detail-packed 4K 30p, with four times the resolution of Full HD. Footage can also be captured in Full HD 60p - ideal for fast-moving sports action. - Cinematic 24p pictures
The camera can also operate in 24p mode, for video footage with a rich, filmic look. - Excellent low light sensitivity
The BRC-X1000 can capture crisp, low noise colour video images in light levels as low as 1.7lx, making it an ideal choice for dimly lit live hall and theater. - Flexible installation
Integration is simplified in a wide range of environments, with PoE+ (Power over Ethernet) to reduce cabling requirements and VISCA control over IP. - Remote operation
Pan/tilt/zoom and other camera settings can be controlled using the supplied IR remote commander, or with the optional RM-IP500 Remote Control Unit that can control multiple cameras. - Genlock
Genlock simplifies integration with other systems in multi-camera broadcast environments. - Front and rear tally lamps
Ideal for on-air broadcast use, the BRC-X1000 features dual tally lamps on the front and rear of the camera body. Brightness of the front tally lamp can be adjusted in two steps. - Simplified construction of VR/AR systems*
Real-time camera tracking data (pan/tilt/zoom/focus/iris) can be output from the camera over IP network in free-d* protocol. It can construct VR/AR system without additional tracking system, easy and cost effective solution.
BRC-X1000 Specification |
|
Image Sensor | 1.0-type back-illuminated Exmor R CMOS sensor |
Image Sensor (Number of Effective Pixels) | Approx. 14.2 Megapixels |
Image Sensor (Total Number of Pixels) | Approx. 20.4 Megapixels |
Signal System | 2160/29.97p, 1080/59.94p, 1080/59.94i, 720/59,94p, 2160/25p, 1080/50p, 1080/50i, 720/50p, 2160/23.98p, 1080/23.98p |
Minimum Illumination (50IRE) | 1.7 lux (50IRE, F2.8, 1/30s, Max.Gain) |
Horizontal Resolution | 1800 TV line (in 3G-SDI output) (center) |
Gain | Auto/Manual (-3dB to +33dB) |
Shutter Speed | 1/10000s to 1/8 (59.94/29.97) 1/10000s to 1/6 (50/25/23.98) |
Exposure Control | Auto, Manual, Priority mode (shutter priority, iris priority, gain priority), Back light, Spot light |
White Balance | Auto1/Auto2/One Push/Indoor/Outdoor/Manual |
Optical Zoom | 12x |
Clear Image Zoom | 2x *1.5x at 4K resolution |
Digital Zoom | No |
Tele Convert Mode | Off, 2x *1920x1080 only |
Focusing System | Auto/Manual |
Horizontal Viewing Angle | 64.6° (Wide-end) |
Focal Length | f=9.3 to 111.6mm F2.8(Wide) ,F4.5(Tele) |
Minimum Object Distance | 1000 mm(Tele) 80 mm(Wide) |
Pan/Tilt Angle | Pan: ±170° Tilt: +90°/-30° |
Pan/Tilt Speed |
Pan: Tilt: *1 When P/T SPEED TYPE setting is NORMAL |
Pan/Tilt Slow Mode | Yes |
Pan/Tilt Operation Noise | NC30 or less* * Sony measurement conditions |
Preset Position | 100 |
PTZ Trace Memory | 16 |
PTZ Motion Sync | Yes |
Camera Tracking Data Output | Yes (Requires firmware V2.10) |
Camera Features |
|
Day/Night | Yes |
Visibility Enhancer | Yes |
Image Flip | On/Off |
Picture Profile Preset | Yes |
ND Filter | Off, 1/4, 1/16, 1/64 switchable in menu |
Color Gain | Yes (15 step) |
Color Hue | Yes (15 step) |
Color Matrix | Off/Standard/High Saturation/FL light/MOVIE/STILL/CINEMA/PRO/ITU709/BW |
Gamma | Standard/Straight/MOVIE/STILL/CINE1/CINE2/CINE3/CINE4/ITU709//Pattern |
Gamma Level | Yes (15 step) |
Black Level | Yes (97 step) |
Black Gamma | Yes (15 step) |
Knee Point | Yes (13 step) |
Knee Slope | Yes (13 step) |
Flicker Cancel | On/Off |
General |
|
Dimensions (W x H x D)*1 | Approx. 198 x 260 x 238mm (without projecting object) Approx. 7 7/8 x 10 1/4 x 9 3/8 inch (without projecting object) |
Mass | Approx. 4.3kg Approx. 9 lb 7.7oz |
Mountable Angle | <±15° |
- Sony BRC-X1000 4K PTZ Camera with 1" CMOS Sensor and PoE+ (Black)
- IR Remote Commander
- Ceiling Bracket A
- Ceiling Bracket B
- Wire Rope
- 7 x M3x8 Mounting Screw
- M4x8 Stainless Steel Screw
- HDMI Cable Clamp
- Limited 1-Year Manufacturer Warranty
