ME-BXC-BU100 Specification |
|
| Compatible optical camera cable | SMPTE 311M camera cable (SMPTE 304 connector) |
| Optical camera cable with OPS2401-P plug OPS2403-J jack manufactured by Tajimi Electronics Co., Ltd. |
|
| Optical signal output | Wavelength 1310nm Light level -9 to -3 dBm Class 1 laser product |
| optical signal loss | 7dB or more |
| camera control signal | RS-422 communication baud rate 115,200bps |
| External device control signal | RS-232C communication Baud rate 115,200bps or less |
| Camera side power supply output | DC48V max 0.8A |
| Power-supply voltage | DC12V-17V |
| power consumption | 17W (excluding camera side power supply and remote control power supply power) Max. 60W (including camera side power supply and remote control power supply power ) |
| operating temperature | 0°C to +40°C |
| operating humidity | 30% to 90% (no condensation) |
| mass | 1.60kg |
| Size | 200mm(W) x 200mm(D) x 42mm(H) (excluding protrusions) |
