The Solidcom H1 ANT01 Antenna is designed to deliver stable, wide-area coverage for Hollyland’s Solidcom H1 wireless intercom system. Supporting productions of any size, the H1 system can operate up to 30 beltpacks without a central station—or scale to 80 beltpacks when paired with the Geo Central Station, all with no license fees required.
Built for Demanding Environments
With a 1640-foot line-of-sight range and seamless roaming, the ANT01 ensures clear communication across large venues, stages, or production sites. Rated IP54 for dust and water resistance, it's ready for both indoor and outdoor use, keeping teams connected in challenging conditions.
Smarter Integration with H1
The ANT01 works seamlessly within the Solidcom H1 ecosystem, supporting up to 12 independent groups on its own, or up to 100 groups when paired with the Geo Central Station. Features like smart app control, cloud communication, and Dante compatibility ensure simple setup and flexible operation.
Details
- Supports 20 to 80 beltpacks (with system)
- 1640' line-of-sight coverage range
- Seamless roaming across zones
- 12 groups standard, 100 with GEO station
- SmartApp control for easy management
- Cloud communication support
- Comprehensive interfaces including Dante
- Rated IP54 dust and water resistant
- PoE powering
|
Solidcom ANT01 Specification |
|
| LOS Range | 500m |
| Operating Frequency |
CE: FCC: |
| Transmit Power |
CE: FCC: |
| Bandwidth | DECT: 1.728 MHz BT: 1 MHz WiFi: 20 MHz |
| Modulation Mode | DECT: GFSK BT: GFSK WiFi: OFDM |
| Receiver Sensitivity | -90 dBm |
| Antenna Gain | 4dB |
| Power Consumption | 15.5W |
| PoE output Power | ≤ 45W |
| PoE Input Power | ≤ 60W |
| V/G Mount Battery Voltage Range | 11V – 30V |
| Dimensions | 302mm x 188.56mm x 64.6mm |
| Weight | 1987g |
| Operation Temperature | -10 ℃ – 45 ℃ |
| Storage Temperature | -20 ℃ – 60 ℃ |
- Hollyland Solidcom ANT01 Antenna
- Fiberglass Antenna x 4
- XLR Network Cable
- PoE Power Adapter
- AC Power Cable
- Quick Guide
- Warranty Card
