The 26V V-Mount/Gold-Mount battery is suited for equipment inputs ranging from 18 to 30VDC. The internal protection chips makes sure there won’t be any over-heating, over-charge, over-discharge and over- current, causing any risk or harm.
With a normal working current of 10 Amps at 26VDC the battery can provide much power. If your equipment uses more than the 10 Amps – you can get a maximum of 15 Amps Output.
The battery is chargeable and can be used in temperatures ranging from -20°C~ +55°C with a Maximum loss in sub zero temperatures of half the capacity.
A 4-level indicator shows you the remaining capacity. There’s a dedicated 26V charger available with a output of 29.4V at 5 Amps. This charger may not be used for any other equipment as the high voltage can kill electronic circuits that are not suitable.
|
26V Battery – 26V / 230Wh V-Mount Battery Specification |
|
| Mount Type | V-Mount |
| Voltage | 26V |
| Capacity | 9.0Ah 230Wh |
| D-Tap In-/Output | Yes (1x) 26V |
| Load | 15.0A (max. ) |
| Dimensions | 108.7(L)mm×74(W)mm×54.4(H)mm |
| Weight | 612g |
|
26V Battery – 26V / 270Wh V-Mount Battery Specification |
|
| Mount Type | V-Mount |
| Voltage | 26V |
| Capacity | 10.5Ah 270Wh |
| D-Tap In-/Output | Yes (1x) 26V |
| Load | 15.0A (max. ) |
| Dimensions | 152(L)mm×97(W)mm×65(H)mm |
- 26V Battery
- 1-year Limited Manufacturer's Warranty
