The versatile, fully featured 4K lens
The UHD-DIGISUPER 90 (UJ90X9B) occupies a unique position in Canon’s 2/3” 4K lens range. It combines true 4K resolution with intelligent features that help you achieve superb results. As an outstandingly versatile 2/3” 4K broadcast field zoom lens, it includes a 90x zoom and 9-810mm focal length (up to 1620mm with the built in 2x extender). So you can cover events that demand a wide range of focal lengths, like sports broadcasts from large stadiums, with just a single lens. Invest in the future standard of 4K broadcasting and pair your 4K camera with this high-quality 4K lens that integrates seamlessly with existing HDTV broadcast use-cases and technical setups.
Impressive optical performance
4K resolution and high contrast are sustained uniformly from the centre to the edge of the image thanks to Canon’s proprietary optical design technologies. Contrast and resolution stay consistently high throughout the focus and zoom ranges, in both the HDTV and 4K frequency bands. Powerful aberration correction features prevent colour bleeding while minimising ghosting and flare. Colours are uniformly reproduced even in the corners of images – creating a visibly superior image, especially when viewed on a large screen.
Shake-free 4K images, even with IS
4K shooting is intolerant of even the smallest camera shake. So the UHD-DIGISUPER 90 (UJ90X9B) features the best of Canon’s optical and servo technologies to stabilise your footage and maintain 4K performance, even with image stabilisation engaged. So from smooth panning shots to beating low or high frequency vibration, your 4K quality remains consistent.
Effortless to use
Operation is straightforward, and great results are easy to achieve, thanks to the UHD-DIGISUPER 90 (UJ90X9B)’s intelligent new design. Canon’s accurate focus demands enable the operator to keep subjects in focus: even in challenging situations like sports broadcasts when long focus is used and a shallow depth of field must be managed.
The lens’ stylish appearance and prominent 4K logo make a great impression on set or location.
Easily step up from HD
There’s no need to change your shooting style when you upgrade from HD to the UHD-DIGISUPER 90 (UJ90X9B). Its size and weight are comparable to a 2/3” HD lens despite its 4K resolution. So there’s no need to get to know new techniques and systems in order to enjoy 4K quality. There’s also no requirement to invest in new accessories, because the servo modules and zoom and focus demands for your existing HD Canon field lenses are fully compatible.
Support for virtual units
It’s easy to use the UHD-DIGISUPER 90 (UJ90X9B) in a virtual system, for example at major sporting events and concerts. It supports a wide range of virtual interfaces for acquiring positional information via either serial communication or output from the 16-bit high-resolution encoder. As it shares connectors and protocols with other Canon HD broadcast lenses, it’s easy to integrate into environments that use Canon HD field or portable lenses.
|
Blackmagic Design HyperDeck Extreme 8K Specification |
|
| Zoom Ratio |
90× |
| Built-in Extender |
2.0× |
| Range of Focal Length |
9-810mm |
| (with Extender) |
18-1620mm |
| Maximum Relative Aperture |
1:2.4 at 9-486mm 1:4.0 at 810mm |
| (with Extender) |
1:4.8 at 18-972mm 1:8.0 at 1620mm |
| Angular Field of View |
16:9 Aspect Ratio (9.6 x 5.4mm): 56.1° × 33.4°at 9mm 0.68° × 0.38°at 810mm |
| (with Extender) |
29.9° × 17.1°at 18mm 0.34° × 0.19°at 1620mm |
| M.O.D. from Lens Front |
3.0m |
| Object Dimensions at M.O.D. |
16:9 Aspect Ratio (9.6 x 5.4mm): 287.9 × 161.9cm at 9mm 3.3 × 1.9cm at 810mm |
| (with Extender) |
144.0 × 81.0cm at 18mm 1.7 × 1.0cm at 1620mm |
| Approx. Size (WxHxL) |
250.6 × 255.5 × 610mm |
| Approx. Mass |
23.2kg |
| Protection Filter | Optional |
| Built-in optical Image Stablilizer | Yes |
