A versatile 4K field lens
Boasting a 66x zoom, the lens is ideal for a wide variety of broadcast situations thanks to advanced optical engineering and a generous use of fluorite and UD glass.
Shake-free 4K images, even with image stabilisation
This lens features the best of Canon’s optical and servo technologies to stabilise your footage and maintain 4K performance, even with image stabilisation engaged.
Impressive optical performance
4K resolution and high contrast are sustained uniformly from the centre to the edge of the image thanks to Canon’s proprietary optical design technologies.
Superb operability and reliability
Great results are easy to achieve, thanks to the lens’ intelligent design. Canon’s accurate focus demands enable the operator to keep subjects in focus at all times.
Full support for virtual systems
The lens supports a wide range of virtual interfaces for acquiring positional information via either serial communication or output from the 16-bit high-resolution encoder.
Canon UJ66x9B Specification |
|
Extender | 2.0x |
Focal Length | 9 – 600 mm (18 - 1200mm with 2x extender) |
Zoom ratio | 66x |
Maximum Relative Aperture (F number) |
1:1.7 (9 - 340 mm) 1:3.0 (600mm) |
Angular Field of View |
56.1° x 33.4° (9mm) 0.92° x 0.52° (600mm) |
Object Dimensions at M.O.D. |
287.9 X 161.9cm at 9mm 4.4 X 2.5cm at 600mm |
Image Coverage | 9.6 X 5.4mm |
M.O.D. (Minimum Object Distance) | 3m |
Shooting Range at M.O.D |
287.9x161.9 cm (9mm) 4.4x2.5 cm (600mm) |
Approx. Size* (W X H X L) |
Approx. 9.9 x 10.1 x 24.0 in Approx. 250.6 x 255.5 x 610 mm |
Approx. Weight | Approx. 51.1 lbs / 23.2 kg |
