Video |
|
Image Sensor | 1/1.7″ Progressive CMOS |
Sensor Size | Diagonal 9.93mm(17:9) |
Effective Pixels | Horizontal: 4096, Vertical: 2160 |
Pixel Size | 1.85 μm (H) x 1.85 μm (V) |
Resolution |
4096 x 2160 3840 x 2160 1920 x 1080 1280 x 720 |
Resolution | Rate |
4K (4096 X 2160) 30 / 29 / 25 / 24p 2160 30 / 29.97 / 25 / 24p 1080p 60 / 59.94 / 50 / 30 / 29.97 / 25p / 24p 1080i 60 / 59.94 / 50i 720 60 / 59.94 / 50 / 30 / 25p |
Output | HDMI 1.4 HD / 3G / 6G-SDI (BNC) |
Color Space | 4 : 2 : 2 (YCbCr) 10bit |
Function |
|
White Balance | AWB / AE / AF |
Exposure | Full Auto, Bright, Shutter Priority, Iris Priority, Manual |
Other | WDR, DIS (Digital Image Stabilization), 2D/3D Noise Reduction, Digital Slow Shutter, Black Level Compensation, Flicker Detection |
Lens |
|
Lens | 12X UHD Optical Zoom Lens, 4.2mm/82° (Wide) ~ 50.04mm/8° (Tele), F1.8 (Wide) – F2.8 (Tele) |
Audio |
|
Input | 3.5mm TRS Stereo Mic-in & Line in over I/O Cable |
Sample Rate | 16/24/32 Bits |
Standard |
|
SMPTE | SMPTE 292M, SMPTE 424M, SMPTE 2081-10 |
Physical |
|
Camera Control | RS-485 VISCA, OSD Button |
Operation Temp | 15°F – 120°F |
Dimension | 90.20mm x 90.20mm x 156.70mm / 3.55″ x 3.55″ x 6.17″ |
Weight | 1987g / 4.38lbs |
Power | 12 VDC (+9 – +15VDC) |
- UHD6G-X12L
- Remote Controller
- USB Cable
- I/O Breakout Cable
- DC 12v Power Supply & Sockets Adaptor
