Video |
|
| Image Sensor | 1/2.5″ Progressive CMOS |
| Sensor Size | Diagonal 7.20mm |
| Effective Pixels | Horizontal: 3840, Vertical: 2202 |
| Pixel Size | 1.62 μm (H) x 1.62 μm (V) |
| Resolution |
2160p: 3840 x 2160 1080p / 1080i : 1920 x 1080 720p : 1280 x 720 |
| Resolution | Rate |
4K 2160p : 30 / 29.97 / 25 / 24 1080p : 60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 1080i : 60 / 59.94 / 50 720p : 60 / 59.94 / 50 |
| Output | HDMI 1.4 |
| Color Space | 4:2:2 (YCbCr) 10bit |
|
Function |
|
| White Balance | AWB / AE / AF |
| Exposure | Full Auto, Bright, Shutter Priority, Iris Priority, Manual |
| Other | WDR, DIS (Digital Image Stabilization), 2D/3D Noise Reduction, Digital Slow Shutter, Black Level Compensation, Flicker Detection |
|
Lens |
|
| Lens | 3X Optical Zoom Lens, 3.85mm/78° (Wide) ~ 13.4mm/25° (Tele) |
|
Physical |
|
| Camera Control | RS-485 VISCA, OSD Button |
| Operation Temp | 32° F – 104° F |
| Dimension | 48mm x 48mm x 83.09mm / 1.89″ x 1.89″ x 3.27″ |
| Weight | 140g / 0.30lbs |
| Power | 12 VDC (+9 – +15VDC) |
- UHD-X3L
- Remote Controller
- USB Cable
- I/O Breakout Cable
- DC 12v Power Supply & Sockets Adapter
