【AIDA Imaging】PTZ4K-NDI-X30W UHD NDI-HX/IP/HDMI PTZ Camera with 30X Zoom (White)

The PTZ4K-NDI-X30 allows you to reinvision your ideas into 4K. Coming packed with outputs via HDMI, NDI®|HX, and USB 3.0 at 4K60p, and being complemented by a gorgeous 4K 1/1.8” Sony CMOS Sensor, this camera outputs 4K 60p video effortlessly. The PTZ4K-NDI-X30 features a 4K 30x optical zoom module capable of capturing video over 150 ft / 50M. The camera also includes your standard AIDA settings, like preset speeds, userfriendly webUI, and other IP protocols such as SRT, RTSP, RTMP, and direct to social media streaming. Have full control over each setting using VISCA over IP, SONY VISCA RS232, or NDI®.

Local Delivery

CHINAM is currently shipping within Hong Kong and specific countries only. We use local courier service as our delivery company. We do not support shipping items in a single order to multiple shipping addresses. To ship items to an additional address, please place a new order to us. Unless otherwise specified, delivery charge at the rate of HK$300 will be imposed on each delivery. We currently offer free delivery for each order over HK$1,000.

For remote areas or outlying islands delivery service, please contact our sales team via email - sales@chinam.com.hk

International Delivery

We will do our best to ship internationally to countries where we do not have sales representation. Please register with us, we’ll keep you updated and notify you when this is about to happen and become available in your region. Please note, at this time the customer is responsible for the duties and taxes imposed by their country.

For international shipping please contact our sales team via email - sales@chinam.com.hk

Deliver Time

  • Once your order has been handed over to the carrier for delivery, you will receive a shipment notification email with an estimated delivery date. Please note that it is not possible to expedite your delivery and receive your package earlier than the scheduled delivery date. Therefore, we are unable to accept requests for expedited delivery. Our carriers are unable to provide an exact time of day for your delivery. If you ordered multiple items, you may receive separate shipments.
  • All estimates are based on business days. We only make deliveries in the specified areas of Hong Kong from Monday to Sunday except on the first two days of the Lunar New Year and when typhoon warning signal No. 8 or above or black rainstorm warning is in force.
  • All rescheduling of delivery, additional purchases, new sales memos and amendments must be made 3 days before the scheduled delivery date. Otherwise, a double delivery charge will be incurred.
  • We may deliver the merchandise in one or more installments, and some of the merchandises may be delivered directly from suppliers. Any times and dates given for dispatch of merchandise, or the length of time that merchandise will take to be delivered, are only estimates. If we are unable to meet any stated dispatch or delivery dates or times we will inform you as to the progress of your order. You agree and accept that under no circumstances will we accept cancellation of order or refund.

Signature On Delivery

  • Most of our shipments contain valuable items. If you will not be in attendance to accept delivery of your purchase, consider shipping to someone you trust will be able to sign for your package. For your convenience, you may prefer to have your order delivered to your office address. If you choose this option, please include the name of your business in the address. Please note, if you choose this option, goods may be left with reception or the Mail Room.
  • As our carriers require a signature on delivery, the carrier will leave a calling card if you are not at home. Please contact the carrier to reschedule delivery.
  • For postal deliveries, no signature is required and order status tracking is not available.
  • Delivery failure due to no one answering the door upon the arrival of goods at the appointed time, or to circumstantial limitations such as the entrance being too small, will require a rescheduled delivery and therefore incur double delivery charges.
  • We will deliver the merchandise ordered by you to the address you give us for delivery at the time you make your order through our staff or a third party provider. You agree to present your photo identification upon request when you acknowledge receipt of the merchandise. The merchandise shall be, and shall be deemed to be, delivered and accepted by you when the merchandise are delivered to the address you give us for delivery. You agree and accept that we are entitled, at our option, to charge you additional costs or cancel your order in the event of your failure to accept delivery for whatever reasons.

General

  • You will become the owner of the merchandise you have ordered when they have been delivered to you. Once merchandise has been delivered to you they will be held at your own risk and we will not be liable for the loss or damage.
  • You may not export any products purchased at CHINAM online store. We sells and ships products to end-user customers only. Notwithstanding order confirmation, CHINAM may cancel any order where it has reasonable grounds to believe the product is not being purchased for end use.
  • If there is any inconsistency or ambiguity between the English version and the Chinese version, the English version shall prevail.
  • We reserve the final right to terminate or alter the above terms and conditions. In the event of any dispute, our decision shall be final and conclusive.
In stock (contact us for lead time)
SKU
PTZ4K-NDI-X30W
Write Your Own Review
You're reviewing:【AIDA Imaging】PTZ4K-NDI-X30W UHD NDI-HX/IP/HDMI PTZ Camera with 30X Zoom (White)
Your Rating
  • NDI®|HX streaming capable for low latency video streaming  and PTZ control over NDI®|HX Protocol.

  • 4K SONY CMOS sensor for crystal clear video up to 60 frames, even in less than ideal video conditions.

  • Advanced digital image processor provides vivid and detailed images with full access feature sets.

  • Motion-compensated temporal noise reduction filter leads to effective noise reduction for motion video without blur.

  • Simultaneous 4K60p over HDMI and NDI®|HX/SRT/RTSP/RTMP!*

  • Simultaneous 4K60p over HDMI and USB3.0*
      *(Disclaimer: USB and NDI®|HX/IP streams will not output simultaneously.)



  • 4K 30x Optical Zoom Module capable of capturing video up to 150ft/50 meters from your subject.

  • 3.5mm Line-in for no audio/video delay over IP/NDI protocols.

  • Built-in OSD controls for customizable image settings.

  • Cost-effective 4K PTZ for entry-level studios looking for UHD quality.

  • Comes in either a White or Black shell for further customization

Video

Image Sensor 1/1.8” Progressive CMOS
Effective Pixels Horizontal: 3840, Vertical: 2160
Pixel Size 2.0 μm (H) x 2.0 μm (V)
Resolution 2160, 1080p & 1080i: 3840x2160, 1920 x 1080
Resolution | Rate

2160 60p / 59.94p / 50p / 30p / 29.97p / 25p / 24p / 23.98p

1080 60p / 59.94p / 50p / 30p / 29.97p / 25p / 24p / 23.98p

1080 60i / 59.94i / 50i

720 60p / 59.94p / 50p / 30p / 29.97p / 25p

Output

HDMI

NDI®|HX / RTSP / RTMP / SRT

USB 3.0

Color Space 4:2:2 (YCbCr) 10bit
Min Illumination 0.1Lux

Function

White Balance Auto, Manual, Auto Tracking, One Push,  Indoor, Outdoor, Temperature
Focus Auto, Manual
Shutter Speed 1 to 1/10,000 Sec.

Lens

Lens 30X 4K Optical Zoom
Focal Length 6.91~214.64mm
Viewing Angle 59° (wide) ~ 1.98° (tele)

PTZ

Pan/Tilt Range Pan: 340°, Tilt: +90 to -30°
Pan/Tilt Speed  Pan: 0° to +120°/s, Tilt: 0° to +80°/s
Presets

128 Positions (via web)

10 Positions (via remote)

Audio

Input  3.5mm TRS Stereo Audio Port
Sample Rate 16 / 24 / 32 Bits

Physical

Camera Control

Protocol: VISCA, VISCA over IP, NDI

Interface: RS-232C IN & OUT, RJ-45

Remote Controller

Operation Temp 32° F – 104° F
Dimension 197mm x 197m x 186mm / 7.75” x 7.75” x 7.3”
Weight 2.1kg / 4.63 lbs
Power

12VDC (+9 - +15VDC)

PoE+ (IEEE802.3at Standard Required)

  • PTZ4K-NDI-X30
  • Remote Controller
  • Camera Mounting Bracket
  • Power Adapter & Cable
  • Safety Harness

View

 PTZ4K-NDI-X30 Datasheet
