Video |
|
Image Sensor | 1/2.5″ Progressive CMOS |
Effective Pixels | Horizontal: 1920, Vertical: 1080 |
Pixel Size | 2.13 μm (H) x 2.13 μm (V) |
Resolution | 1080p & 1080i: 1920 x 1080 |
Resolution | Rate |
1080 60p / 59.94p / 50p / 30p / 29.97p / 25p / 24p / 23.98p 1080 60i / 59.94i / 50i 720 60p / 59.94p / 50p / 30p / 29.97p / 25p |
IP Rate |
1920 x 1080 @ 1~60 |
Output |
HD-SDI/3G-SDI |
Color Space | 4:2:2 (YCbCr) 10bit |
Min Illumination | 0.1Lux |
Function |
|
White Balance | Auto, Manual, Auto Tracking, One Push, Indoor, Outdoor |
Focus | Auto, Manual |
Shutter Speed | 1 to 1/10,000 Sec. |
Lens |
|
Lens | 12X HD Optical Zoom |
F-Stop | F1.5 ~ F3.0 |
PTZ |
|
Pan/Tilt Range |
Pan: 340° Tilt: +90 to -30° |
Pan/Tilt Speed |
Pan: 0° to +120°/s Tilt: 0° to +80°/s |
Presets |
128 Positions (via web) |
Field of View |
72.5° |
Standard |
|
SMPTE | SMPTE 292M, SMPTE 424M |
IP Protocol | TCP|IP, RTSP|RTMP |
Audio |
|
Input | 3.5mm TRS Stereo Audio Port |
Sample Rate | 16 / 24 / 32 Bits |
Physical |
|
Camera Control |
Protocol: VISCA, VISCA over IP, NDI Interface: RS-232C IN & OUT, RJ-45 Remote Controller |
Operation Temp | 32° F – 104° F |
Dimension | 155mm x 160m x 170mm / 6.10” x 6.92” x 6.69” |
Weight | 1.35kg / 2.97lbs |
Power |
12VDC (+9 - +15VDC) PoE+ (IEEE802.3at Standard Required) |
- PTZ-NDI-X12
- Remote Controller
- Camera Mounting Bracket
- USB 3.0
- Power Adapter & Cable
