Synchronization |
|
Input | 3G-SDI / HD-SDI |
Resolution|Rate |
1080p : 60 / 59.94 / 50 / 30 / 29.97 / 25 p 1080i : 60 / 59.94 / 50i 720p : 60 / 59.94 /30p/ 25p |
Color Space | 4:2:2 (YCbCr) 10bit |
Output | Genlocked HD-SDI/3G-SDI Genlocked HDMI 1.3a |
Function |
|
Genlock | ON/OFF H Sync & V Sync Adjustment |
Audio Control | Audio Bits (16, 20, 24 Bits) |
Payload ID | ON/OFF |
Pattern Generate | Thirteen Patterns |
Audio |
|
Input | 16 Channels Embedded SDI Audio |
Standard |
|
SMPTE | SMPTE 292M, SMPTE 424M |
Physical |
|
Camera Control |
OSD Button & Text LCD |
Operation Temp | 32° F – 104° F |
Dimension | 130mm x 75m x 24mm / 5.11″ x 2.95″ x 0.94″ |
Weight | 173g / 0.38lbs |
Power |
6W at 12VDC (+9 – +15VDC) |
- GCON-SDI
- DC 12v Power Supply & Sockets Adapter
