- Full-HD 1/2.8” Progressive Scan CMOS sensor capable of 1080 60p NDI® HX and 3G-SDI video.
- Accessible Web UI to stream directly to social media platforms and control image parameters over IP.
- Versatile and discreet design perfect for sleek, multi-leveled image capturing in most scenarios.
- OSD breakout cable provides power or control over serial RS485 communication.
- Flawlessly relays multi-channel embedded audio via NDI® HX2
- Perfectly suited for upgrading existing 3G-SDI workflows to IP / NDI® HX capabilities.
| VIDEO | |
| Image Sensor | 1/2.8” Progressive CMOS |
| Effective Pixels | Horizontal: 1920, Vertical: 1080 |
| Pixel Size | 2.9 μm (H) x 2.9 μm (V) |
| Resolution | 1080p, 1080i, 720p |
| Resolution Rate | 1080 60p/59.94/50p/30p/29.97p/25p 24p/23.98p 1080 60i/59.94i/50i 720 60p/59.94p/50p/30p/29.97p/25p |
| Output | 3G-SDI, RJ45, NDI® HX2 |
| IP Rate | 1920 x 1080 @ 3~60 1280 x 720 @ 3~60 1024 x 576 @ 3~60 620 x 360 @ 3~60 |
| Color Space | 4:2:2 (YCbCr) 10bit |
| PHYSICAL | |
| Camera Control | Protocol: VISCA RS485, VISCA Over IP Control: OSD Button or Web UI |
| Operation Temp | 32°F - 104°F |
| Dimension | 54mm x 54mm x 127mm / 2.125” x 2.125” x 5” (With default 4mm Lens) |
| Power | 12VDC (+9 - +15VDC)/ POE |
| LENS | |
| Lens | Custom Varifocal 5-50mm Lens HFOV: Wide: 51° Tele’d: 6.1° |
| AUDIO | |
| Input | 3.5mm TRS Stereo Audio Port |
| Sample Rate | 16/24/32 Bits |
- I/O Breakout Cable
- DC 12v Power Supply & Sockets Adapter
- 4mm Megapixels Lens(Pre-Installed)
- USB Cable
- C-Mount Cap Adapter
- Sensor Cap
