- Full-HD 1/2.8” Sony Progressive Scan CMOS sensor capable of 1080 60p through 3G-SDI
- VISCA over IP compatible for hardware and software solutions using that protocol. (VISCA UDP, SONY VISCA over IP)
- Versatile designs with tripod mounts for easy and unique shot creation.
- PoE+ adaptable with adapter (comes with purchase of the camera)
- Variants for weatherproofed cameras, capable of IPV54 and above rating.
- CS-mount lens, M12 mount lens, and varifocal weatherproof options available.
- Small form-factor and rugged designed makes all video streaming applications possible
- Perfectly suited for indoor or outdoor shots for new or existing workflows.
|
VIDEO |
|
| Image Sensor | 1/2.8” Progressive CMOS |
| Sensor Size | 5.640mm x 3.216mm (16.9) |
| Effective Pixels | Horizontal: 1920, Vertical: 1080 |
| Pixel Size | 2.9 μm (H) x 2.9 μm (V) |
| Resolution | 1080p, 1080i, 720p |
| Resolution Rate |
1080 60p/59.94/50p/30p/29.97p/25p 24p 1080 60i/59.94i/50i 720 60p/59.94p/50p |
| Output | 3G-SDI |
| Color Space | 4:2:2 (YCbCr) 10bit |
| Min Illumination | 0.2Lux (day), 0.1Lux (Night) |
| White Balance | Auto & Manual (9000 - 11,000 K) |
| Audio Input | 3.5mm TRS Stereo Input, Embed over SDI |
| PHYSICAL | |
| Camera Control | RJ45 (VISCA over IP) RS485 (Serial VISCA) |
| Operation Temp | -10°C~50°C |
| Power | 12VDC (+9 - +15VDC) (PoE Adapter Included) |
| Power Draw | 6W MAX |
| LENS | |
| Lens |
CS mount 4mm Lens HFOV: 80° |
- PoE Dongle Adapter
- DC 12v Power Supply & Sockets Adapte
